F115 // F130
F115 // F130
Delivering the best power-to-weight in their class
The latest-generation, lightweight designs F115 and F130 let you relax and enjoy your boat to the full - knowing you're powered by the cleanest, smoothest engines on the planet.
Not only is the engineering impressive - these are 1.8 litre, 16 big-Valve, in-line, 4-cylinder, DOHC, 4-stroke engines - but they are blended with a host of electro/technical features to make life easier, such as: Compatibility with our optional Digital Network System, Y-COP® remote security, Wide Range Power Trim & Tilt with Tilt angle limiter option, to name but a few.
The efficiency of our well proven EFI systems and other new combustion technologies ensure the utter dependability of these outstanding Yamaha engines.
Technical Specifications
| Engine type: | 4-stroke// |
| Displacement: | 1,832 cm³//1,832 cm³ |
| No. of cylinders/configuration: | 4/In-line, 16-valve, DOHC//4/In-line, 16-valve, DOHC |
| Bore x stroke: | 81.0 mm x 88.9 mm//81.0 mm x 88.9 mm |
| Prop shaft output at mid range: | 95.6kW / 6,300 rpm//95.6kW / 6,300 rpm |
| Full throttle operating range: | 5,300 - 6,300 rpm//5,300 - 6,300 rpm |
| Lubrication system: | Wet sump//Wet sump |
| Fuel Induction System: | EFI//EFI |
| Ignition / advance system: | TCI//TCI |
| Starter system: | Electric with Prime Start™//Electric with Prime Start™ |
| Gear ratio: | 2.15 (28/13)//2.15 (28/13) |
| Recommended boat transom height: | L:516mm X643mm//L:516mm X643mm |
| Weight with propeller: | F130AETL: 174.0 kg, F130AETX: 178.0 kg |
| Weight with propeller: | F115BETL: 173.0 kg, F115BETX: 177.0 kg, FL115BETX: 177.0 kg |
| Oil pan capacity: | 3.2 litres// |
| Control: | Remote Control//Remote Control |
| Trim & tilt method: | Power Trim & Tilt//Power Trim & Tilt |
| Lighting Coil / Alternator: | 12V - 35A with rectifier/regulator//12V - 35A with rectifier/regulator |
| Tilt limitter (only for remote control specs): | Option//Option |
| Engine immobiliser: | YCOP//YCOP |
| Propeller: | Options available//Optional |
| Counter Rotation Model: | - //Available (ETX) |
| Shallow Water Drive: | Standard//Standard |
| Digital Network Gauge (Round/Square): | Option//Optional |
| Shift Dampener System (SDS): | Option//Optional |
| Shift Dampener System (SDS): | Option//Optional |
| Remark: | The kW data in this sheet is based on the ICOMIA 28 standard, measured at the prop shaft |
