The unique V8 power solution for larger boats

Created for the heavy-duty demands of large offshore boats, the 5.3 litre Yamaha F350 is a mighty technological pioneer. This 4-stroke V8 is the world's largest displacement outboard, combining unique levels of power and torque with the refined performance required by today's sophisticated hull designs.

Yamaha's EFI (Electronic Fuel Injection) delivers smooth performance and maximum fuel efficiency across the power band - and despite its size and power, Yamaha's weight-saving technologies have made the F350 surprisingly light and compact too.

With the PrimeStart™ system, starting is as easy as in your car - and digital drive-by-wire technology keeps you in precise control.

Technical Specifications

Engine type: 4-stroke
Displacement: 5,330 cm³
No. of cylinders/configuration: 60°-V8, 32-valve, DOHC
Bore x stroke: 94.0 mm x 96.0 mm
Prop shaft output at mid range: 257.4kW / 5,500 rpm
Full throttle operating range: 5,000 - 6,000 rpm
Lubrication system: Wet sump
Fuel Induction System: EFI
Ignition / advance system: TCI
Starter system: Electric with Prime Start™
Gear ratio: 1,73 (26/15)
Recommended boat transom height: X:637mm U:764mm
Weight with propeller: 350AETX: 356.0 kg, FL350AETX: 356.0 kg, F350AETU: 364.0 kg, FL350AETU: 364.0 kg
Oil pan capacity: 6.5 litres
Control: Drive By Wire (DBW)
Trim & tilt method: Power Trim & Tilt
Lighting Coil / Alternator: 12V - 49A with rectifier/regulator
Tilt limitter (only for remote control specs): Standard
Engine immobiliser: YCOP
Propeller: Optional
Counter Rotation Model: Available (ETX, ETU)
Shallow Water Drive: Standard
Digital Network Gauge II (LCD Color): Optional
Digital Network Gauge (Round/Square): Optional
Variable Trolling RPM: With DN Gauges or m-f tiller handle
Dual Battery Charging System: Optional
Shift Dampener System (SDS): Optional
Remark: The kW data in this sheet is based on the ICOMIA 28 standard, measured at the prop shaft
